LPG Storage Tanks - Horizontal
LPG Storage Tanks - Horizontal
Technical Drawing
| PRODUCT CODE |
VOLUME (LITERS) |
A (mm) |
B (mm) |
C (mm) |
D (mm) |
E max (mm) |
| LHT 1000 | 1000 | 800 | 1750 | 850 | 2200 | 1300 |
| LHT 1800 | 1800 | 1000 | 1800 | 900 | 2380 | 1500 |
| LHT 3000 | 3000 | 1200 | 2250 | 1100 | 2975 | 1700 |
| LHT 3850 | 3850 | 1200 | 3000 | 1500 | 3725 | 1700 |
| LHT 5000 | 5000 | 1200 | 4000 | 2000 | 4725 | 1700 |
| LHT 7000 | 7000 | 1600 | 3000 | 1500 | 3900 | 2160 |
| LHT 10000 | 10000 | 1600 | 4500 | 3300 | 5392 | 2160 |
| LHT 10000 | 10000 | 1900 | 2850 | 1850 | 3974 | 2420 |
| LHT 22000 | 22000 | 2350 | 4500 | 3300 | 5745 | 2850 |
| LHT 40000 | 40000 | 2400 | 8000 | 4000 | 9350 | 2900 |
| LHT 50000 | 50000 | 2400 | 10500 | 5250 | 11850 | 2900 |
| LHT 100000 | 100000 | 2950 | 13500 | 6750 | 15170 | 3500 |
| LHT 115000 | 115000 | 3000 | 15500 | 7750 | 17150 | 3500 |
| LHT 150000 | 150000 | 3150 | 18250 | 9600 | 19930 | 3500 |
| LHT 200000 | 200000 | 3500 | 20000 | 11000 | 21950 | 3600 |
| LHT 250000 | 250000 | 3500 | 24800 | 12375 | 26700 | 3600 |
You can contact our authorized team member regarding the issue.
